Rocker Switch
From marine helm panels to agricultural sprayers and outdoor power distribution, our rocker switches are built to survive moisture, vibration, and daily abuse. Choose from single-pole/double-pole, multiple actuator colors, and custom legends — all backed by CE, RoHS compliance.
Online Service
Product Detail
| Feature | Options |
|---|---|
| Circuit configuration | SPST, SPDT, DPST, DPDT |
| Operation | Momentary, Latching |
| Illumination | No LED / Single color / Bi-color (red/green/blue/amber/white) |
| Voltage rating | 12V DC, 24V DC, 48V DC, 125V AC, 250V AC |
| Current rating | 10A, 15A, 20A (depends on model) |
| Panel cutout | 19.2×13mm, 22×30mm, 27×22mm, or custom |
| IP rating | IP65 (dust & water jets), IP67 (temporary immersion), IP68 (continuous) |
| Housing material | Stainless steel (marine grade) or UL94 V-0 flame-retardant nylon |
| Actuator shape | Oval, rectangular, rounded – glossy or matte finish |
| Mechanical life | 50,000 – 100,000 cycles |
-
Custom laser marking: symbols, logos, text (e.g., ON/OFF, AUTO, START)
-
LED voltage & color: 6V, 12V, 24V, 110V, 220V; single or dual color
-
Actuator texture & color: choose from black, grey, red, blue, or custom pantone
-
Seal upgrade: IP68 with silicone boot and epoxy-sealed terminals
-
Wire harness: pre-assembled with connector and heat shrink
-
Marine dashboards & navigation light controls
-
Agricultural sprayers, seeders, and utility vehicles
-
Off-highway equipment (excavators, compact tractors)
-
Outdoor power distribution boxes & EV charging stations
-
Food processing machinery (washdown environment)
-
Medical carts and diagnostic equipment
